BZC Series Explosion Proof Control Station Aluminium For Explosion Endangered Zones
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy,powder coated surface |
| Dimensions | As design |
| Enclosure colour | Window grey(RAL7040) |
| Exposed fastener | Stainless steel |
| Rated voltage | Max.415V AC |
| Rated current | 10A |
| Internal&external earthing | I, II, III: M6/M6; IV, V, VI : M6/M8 |
| Cable entries | Standard M□ x 1.5 plug. Please see the Selection table on P4/7 |
| Cable gland(optional) | DQM-II (Ex d),DQM-III (Ex d) is recommended |
| Mounting | Surface type |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 11.0043 |
| Gas and dust | Ex db IIB+H2 T6 Gb |
| Ex tb IIIC T80℃ Db IP66 | |
| Europe (ATEX) | TUV CY 17 ATEX 0205967X |
| Gas and dust | Ex II 2 G Ex db IIB+H2 T6 Gb |
| Ex II 2 D Ex tb IIIC T80℃ Db IP66 | |
| Certificates | IECEx; ATEX; CU-TR |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66 |
| Ambient temperature | -60℃~+55℃ |
