BZC8050 Series Aluminium Alloy Control Station IP65 Protection ATEX IECEx Certified
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy, powder coated surface |
| Dimensions | As per design |
| Enclosure colour | Window grey (RAL7040) |
| Exposed fastener | Stainless steel |
| Rated voltage | Max. 500V/440V AC |
| Max.220V DC | |
| Rated current | 16A,10A |
| Internal&external earthing | I, II, III: M4/M4; IV, V, VI,VII: M6/M6 |
| Cable entries | M□ x 1.5 plug |
| Cable gland (optional) | DQM-I (Ex e) |
| Mounting | Surface type |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 24.0057X |
| Gas and dust | Ex db eb mb IIC T6/T5 Gb |
| Ex db eb IIC T6/T5 Gb | |
| Ex tb IIIC T80℃ Db | |
| Europe (ATEX) | TUV CY 25 ATEX 0207269X |
| Gas and dust | Ex II 2 G Ex db eb mb IIC T6/T5 Gb |
| Ex II 2 G Ex db eb IIC T6/T5 Gb | |
| Ex II 2 D Ex tb IIIC T80℃ Db | |
| Certificates | IECEx; ATEX; CU-TR |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66 |
| Ambient temperature | -60℃(-40℃)~+55℃(+40℃) |
