BZA8050 Series Explosion proof Control Unit System GRP Material Black Color
Download Brochure| Data | |
|---|---|
| Material | GRP (glass fibre-reinforced polyester resin) |
| Dimensions | As per design |
| Enclosure colour | Black |
| Exposed fastener | Stainless steel |
| Rated voltage | Max. 415V AC |
| Rated current | 10A(ATEX), 6A(IECEx) |
| Cable entries | 1 x M25 x 1.5 cable gland |
| Available cable outer diameter | Φ9~Φ16 (mm) |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 11.0018 |
| Gas | Ex d e IIC T6 Gb |
| Europe (ATEX) | LCIE 09 ATEX 3097 |
| Gas | Ex II 2 G Ex d e IIC T6 |
| Certificates | IECEx; ATEX; |
| Conformity to standards | EN; IEC |
| Degree of protection | IP65 |
| Ambient temperature | -20℃~+55℃ |
