BZA85 Series Aluminium Control Unit System Explosion Proof Hazardous Areas Equipment
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy, powder coated surface |
| Dimensions | As per design |
| Enclosure colour | Window grey (RAL7040) |
| Exposed fastener | Stainless steel |
| Rated voltage | Max.500V AC, 250V DC(600V for voltmeter) |
| Rated current | Max.10A (AC), 6A (DC) |
| Cable entries | Standard 2 x M25 x 1.5 plugs |
| 2 x NPT3/4" plugs on request | |
| Cable gland (optional) | DQM-II(Ex d) or DQM-III(Ex d) is recommended |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 17.0021X |
| Gas and dust | Ex db IIC T6 Gb |
| Ex tb IIIC T80℃ Db IP66 | |
| Europe (ATEX) | TUV CY 18 ATEX 0206093 X |
| Gas and dust | Ex II 2 G Ex db IIC T6 Gb |
| Ex II 2 D Ex tb IIIC T80℃ Db IP66 | |
| Certificates | IECEx; ATEX; CU-TR |
| Conformity to standards | EN;IEC |
| Degree of protection | IP66 |
| Ambient temperature | -60℃~+60℃ |
