BL8060 Series Explosion Proof Circuit Breaker Module With GRP Enclosure Flame Proof
Download Brochure| Data | |
|---|---|
| Enclosure Material | GRP(glass fibre-reinforced polyester resin) |
| Dimensions | As per design |
| Rated voltage | Max.690V AC 50/60Hz, Max. 500V DC |
| Rated current | 1A, 2A, 4A, 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A |
| Mechanical life | 20000 times |
| Auxiliary contact | 1NO+1NC (indicating contact in OFF state) |
| Nunmber of pole | 1P, 2P,3P,4P 1PL,2PL |
| Ambient temperature | -20℃~+70℃ |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 14.0031U |
| Gas | Ex db eb IIC Gb |
| Europe (ATEX) | EUT 14 ATEX 1301U |
| Gas | Ex II 2 G Ex db eb IIC Gb |
| Certificates | IECEx; ATEX |
| Conformity to standards | EN 60079-0, EN 60079-1, EN 60079-7 |
| IEC 60079-0, IEC 60079-1, IEC 60079-7 | |
