HRMD95 Series-Proof Distribytion Panels With Specialized Hinge Structure
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy, powder coated surface,Window grey (RAL7040) |
| Dimensions | As per design |
| Rated voltage | MAX. 1000V AC 50/60Hz; MAX. 1500V DC |
| Rated current | Max.2000A |
| Internal&external earthing | M8/M8 |
| Cable entries | Standard MX1.5 plug |
| Specification | |
|---|---|
| Global (IECEx) | IECEx PCET 24.0030X |
| Gas and Dust | Ex db llB+H2 T口'Gb |
| Ex db fia Ga]lB+H2 Tㄩ"Gb | |
| Ex db [ib Gb] lB+H T口"Gb | |
| Ex tb llC T’Db | |
| Europe (ATEX) | applied for |
| Gas and Dust | Ex ll 2 G Ex db llB+H2 T口'Gb |
| Ex ll 2 G Ex db [ia Ga] llB+H2 T口"Gb | |
| Ex ll2 G Ex db [ib Gb] llB+H2 T口"Gb | |
| Ex II 2 D Ex tb llIC T口"Db | |
| 'See table for max. dissipated power | |
| Certificates | IECEx; ATEX; |
| Conformity to standards | EN 60079-0, EN 60079-1, EN 60079-11, EN 60079-31 |
| IEC 60079-0, IEC 60079-1, IEC 60079-11, IEC 60079-31 | |
| Degree of protection | IP66 |
| Ambient temperature | -60℃(-40℃)≤Ta≤+40(+60℃) |
