BHD51 Series Ex Proof Flame Proof Junction Box Weatherproof For Hazardous Area
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy or cast iron, powder coated surface |
| Weight | 0.7kg~2.1kg |
| Dimensions | 117mm×122×80mm |
| Enclosure colour | Yellow (RAL1021) |
| Exposed fastener | Stainless steel |
| Rated voltage | Max. 500V AC |
| Rated current | 20A |
| Internal&external earthing | M4/M5 |
| Cable gland(optional) | DQM-II(Ex d), DQM-III(Ex d) |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 11.0022X |
| Gas and dust | Ex db IIC T6 Gb |
| Ex tb IIIC T80℃ Db | |
| Europe (ATEX) | CNEX 21 ATEX 0001X |
| Gas and dust | Ex II 2 G Ex db IIC T6 Gb |
| Ex II 2 D Ex tb IIIC T80℃ Db | |
| Certificates | IECEx; ATEX; CU-TR |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66 |
| Ambient temperature | -60℃~+60℃ |
