BHD91 Series Round Explosion Proof Electrical Junction Box IP66 IECEx ATEX Certificated
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy, powder coated surface |
| Weight | 1.2kg |
| Dimensions | 146mm×163mm×100mm |
| Enclosure colour | Window grey (RAL7040) |
| Exposed fastener | Stainless steel |
| Rated voltage | Max. 500V AC |
| Rated current | 24A, 32A, 41A |
| Internal & external earthing | M5/M5 |
| Cable gland(optional) | DQM-II(Ex d), DQM-III(Ex d) |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 15.0061X |
| Gas and dust | Ex db IIC T6 Gb |
| Ex tb IIIC T80℃ Db IP66 | |
| Europe (ATEX) | CNEX 16 ATEX 0006 |
| Gas and dust | Ex II 2 G Ex db IIC T6 Gb |
| Ex II 2 D Ex tb IIIC T80℃ Db IP66 | |
| Certificates | IECEx; ATEX; CU-TR;UL |
| Conformity to standards | EN;IEC |
| Degree of protection | IP66 |
| Ambient temperature | -60℃~+60℃ |
