BXJ8050-20/6 Series Explosion Proof Junction Boxes Stainless Steel IP65 Flameproof
Download Brochure| Data | |
|---|---|
| Material | GRP(glass fibre-reinforced polyester resin) |
| Weight | 0.65kg~0.8kg |
| Dimensions | As per design |
| Enclosure colour | Black |
| Exposed fastener | Stainless steel |
| Rated voltage | Max. 500V AC |
| Rated current | 20A |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 07.0013 |
| Gas | Ex e II T6 |
| Europe (ATEX) | PTB 15 ATEX 1016X |
| Gas and dust | Ex II 2 G Ex e IIC T6 Gb |
| Certificates | IECEx; ATEX; CU-TR |
| Conformity to standards | EN; IEC |
| Degree of protection | IP65 |
| Ambient temperature | -20℃~+55℃ |
