BXJ-IIB Series Explosion Proof Terminal Boxes Aluminium Alloy For Hazardous Area
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy, powder coated surface |
| Weight | 7.5kg~93.1kg |
| Dimensions | According to design |
| Enclosure colour | Window grey (RAL7040) |
| Exposed fastener | Stainless steel |
| Rated voltage | Max. 800V AC |
| Rated current | 24A~ 400A |
| Internal&external earthing | M6/M6, M8/M8 |
| Cable gland(optional) | DQM-II(Ex d), DQM-III(Ex d) |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 14.0061X |
| Gas and dust | Ex db IIB+H2 T6 or T5 Gb |
| Ex tb IIIC T80℃ or T95℃ Db IP66 | |
| Gas and dust | Ex II 2 G Ex db IIB+H2 T6 or T5 Gb |
| Ex II 2 D Ex tb IIIC T80℃ or T95℃ Db IP66 | |
| Certificates | IECEx; ATEX; CU-TR |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66 |
| Ambient temperature | -60℃~+40℃ (T6/T80℃) |
| -60℃~+55℃ (T5/T95℃) | |
