BNG Series Metal Explosion Proof Flexible Conduits Stainless Steel M20~M63 Thread
Download Brochure| Data | |
|---|---|
| Material | Stainless steel body;connectors at both ends in stainless steel |
| Type | F/F, M/F, M/M |
| Connection thread | Metric thread is standard type; G thread or NPT thread is optional |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 11.0014U |
| Gas and dust | Ex db IIC Gb |
| Ex tD A21 IP66 | |
| Europe (ATEX) | DNV 10 ATEX 87636U |
| Gas and Dust | Ex II 2 G Ex d IIC Gb |
| Ex II 2 D Ex tD A21 IP66 | |
| Certificates | IECEx; ATEX; CU-TR |
| Conformity to standards | EN;IEC |
| Degree of protection | IP66 |
| Ambient temperature | -60℃~+55℃ |
