BAJ52-20 2 x 10W LED Light Fittings Explosion Proof Emergency Light IECEx ATEX
Download Brochure| Data | |
|---|---|
| Available lamp | Halogen tungsten lamp (LED on request) |
| Lamp power (W) | 2 x 10W (LED lamp power: 2 x 1W) |
| Emergency time | 90min |
| Rated luminous flux | Halogen tungsten lamp: 2 x 100lm (LED lamp: 2 x 90lm) |
| Description | Ni-MH battery |
| Rated capacity | 6Ah |
| Rated voltage | 6V |
| Charging current | 300mA |
| Discharging current | 1000mA |
| Charging time | 24h |
| Ambient temperature | -20℃~+55℃ |
| Terminal | 3 x 1.5~2.5mm2 (L+N+PE) |
| Cable entries | 2 x M25 x 1.5 plugs |
| Cable gland (optional) | DQM-II (Ex d) or DQM-III (Ex d) is recommended. |
| Weight | 5.05kg |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 08.0001 |
| Gas and dust | Ex d IIB T4 |
| Europe (ATEX) | LCIE 07 ATEX 6086 |
| Gas and dust | Ex II 2 G Ex d IIB T4 |
| Certificates | IECEx; ATEX |
| Conformity to standards | EN; IEC |
| Degree of protection | IP65 |
