BAK51 Series Tank Inspection Vessel LED Light Fittings Explosion Proof IP66 35W 50W
Download Brochure| Data | |
|---|---|
| Enclosure | Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021) |
| Glass cover | Toughened glass, impact resistance and high light transmission |
| Exposed fastener | Stainless steel |
| Available lamp | Halogen tungsten lamp |
| Lamp holder | GY6.35 |
| Lamp power (W) | 35W, 50W |
| Adaptable voltage | DC 12V |
| Rated voltage | 220~240V AC 50Hz,12V DC; 24V AC/DC |
| Earthing protection | M5 (internal & external earth bolts) |
| Ambient temperature | -60℃~+60℃ |
| Terminal | 3 x 1.5~2.5mm2 (L+N+PE) |
| Cable entries | 1 x G3/4" |
| Cable gland | Supplied with seal gasket and gland nut, cable gland on request. |
| Available cable outer diameter | Φ10~Φ14 (mm) |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CNEX 18.0033X |
| Gas and dust | Ex db IIB T3 Gb |
| Ex tb IIIC T190℃ Db | |
| Europe (ATEX) | CNEX 18 ATEX 0026 X |
| Gas and dust | Ex II 2 G Ex db IIB T3 Gb |
| Ex II 2 D Ex tb IIIC T190℃ Db IP66 | |
| Certificates | IECEx; ATEX |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66 |
