BAK85 Series LED Tank Inspection Vessel Light Fittings Explosion proof 9W 5700K
Download Brochure| Data | |
|---|---|
| Enclosure | Copper-free Aluminium Alloy, powder coated surface, yellow |
| (RAL1021) | |
| Glass cover | Toughened glass, stands 4J impact |
| Exposed fastener | Stainless steel |
| Lamp specification | International brand of LED module |
| Lamp power (W) | 9W |
| Colour Temperature (CCT) | 5700K |
| Rated voltage | 100~277V AC 50/60Hz,100~250V DC,12~36V AC,12~48V DC |
| Earthing protection | M5 (internal & external earth bolts) |
| Ambient temperature | -40℃~+55℃ |
| Terminal | 3 x 1.5~2.5mm2 (L+N+PE) |
| Cable entries | M20 x 1.5 |
| Cable gland | Supplied with seal gasket and gland nut |
| Available cable outer diameter | Φ6~Φ12 (mm) |
| Specification | |
|---|---|
| Global (IECEx) | IECEx TPS 18.0011X |
| Gas and dust | Ex db op is IIC T6 Gb |
| Ex tb op is IIIC T80℃ Db | |
| Europe (ATEX) | TPS 18 ATEX 089761 0007X |
| Gas and dust | Ex II 2 G Ex db op is IIC T6 Gb |
| Ex II 2 D Ex tb op is IIIC T80℃ Db | |
| Certificates | IECEx; ATEX |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66/IP67 |
