BSZD81-C Series Explosion Proof Caution Spotlight Fittings 40W for industrial areas
Download Brochure| Data | |
|---|---|
| Enclosure | Copper-free Aluminium Alloy, powder coated surface, yellow |
| (RAL1021) | |
| Transparent cover | Toughened glass, stands 4J impact |
| Exposed fastener | Stainless steel |
| Rated voltage | 100V, 110V, 120V, 127V, 220V, 230V, 240V AC 50/60Hz |
| Lamp specification | LED |
| Lamp power (W) | 40W (continuous work) |
| Lamp colour | Red |
| Max. luminous intensity value | ＞2000cd |
| Flash frequency | 16, 20, 30, 40, 60, 80, 120, 240 (times/min) |
| Earthing protection | M5 (internal & external earth bolts) |
| Ambient temperature | -40℃~+55℃ |
| Terminal | 3 x 1.5~2.5mm2 (L+N+PE) |
| Cable entries | 4 x M25 x 1.5 plugs |
| Cable gland | DQM-I (Ex e) is recommended. |
| Weight | 13.8kg |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 11.0026X |
| Gas and dust | Ex d e IIC T6 Gb, |
| Ex tb IIIC T80℃ Db IP65 | |
| Europe (ATEX) | EUT 14 ATEX 1155 |
| Gas and dust | Ex II 2 G Ex d e IIC T6 Gb |
| Ex II 2 D Ex tb IIIC T80℃ Db IP65 | |
| Certificates | IECEx; ATEX; CU-TR |
| Conformity to standards | EN; IEC |
| Degree of protection | IP65 |
