BAT53 Series Explosion Proof Led Flood Light 70W-1000W For Hazardous Areas
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy,powder coated surface,yellow (RAL1021), |
| Toughened glass,stands 4J impact | |
| Weight | 8.45~115kg |
| Dimensions | different power has different dimension |
| Lamp specification | HIE HSE HME |
| Lamp power (W) | 70~1000W |
| Rated voltage | 220-240V AC 50HZ(60H is optional) |
| Rated luminous flux | 3800~56500lm |
| Terminal | 3 x 1.5~2.5mm2 (L+N+PE) |
| Cable entries | 2×Φ21:1×M20×1.5 cable gland ,1×M20×1.5 plug |
| Available cable outer diameter | Φ5~Φ10 (mm) |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 13.0037X |
| Gas and dust | Ex d e IIB T□ 1) Gb |
| Ex tb IIIC T□1) Db IP66 | |
| Europe (ATEX) | EPT 18 ATEX 2930X |
| Gas and dust | Ex II 2 G Ex db e IIB T□1) Gb |
| Ex II 2 D Ex tb IIIC T□1) Db | |
| Certificates | IECEx; ATEX；CU-TR |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66 |
| Ambient temperature | -60℃~+55℃ |
