BAY51-Q Series Explosion Proof Fluorescent Light Fittings T8 Tube Corrosion Proof
Download Brochure| Data | |
|---|---|
| Material | GRP, stands 7J impact, corrosion-proof |
| Weight | 6.8~12.2kg |
| Dimensions | 1332x222x134mm |
| Lamp specification | T8 tube |
| Lamp power (W) | 36W(18W) x 2； 36W(18W) x 1 |
| Emergency power (W) | 36W(18W) x 1 |
| Emergency starting time | 0.3s |
| Charging time | 24h |
| Emergency lighting time | 120/180 Mins |
| Rated voltage | 96~277V AC 50/60Hz |
| Rated luminous flux | 1300~6500lm |
| Terminal | 3 x 1.5~4mm²(L+N+PE) |
| Cable entries | 2xΦ26:2xM25X1.5 cable glands(DQM-I EX e,plastic). |
| Available cable outer diameter | Φ9~Φ16 (mm) |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 07.0007X |
| Gas and dust | Ex db eb q IIC T4 Gb; Ex tb IIIC T85℃ Db |
| Europe (ATEX) | LCIE 12 ATEX 3045X |
| Gas and dust | Ex II 2 G Ex db eb q IIC T4 Gb |
| Ex II 2 D Ex tb IIIC T85℃ Db | |
| Certificates | IECEx; ATEX; CU-TR |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66 |
| Ambient temperature | -40℃~+60℃ |
