HRD91-LED Series Explosion Proof Led Lighting 30W 50W 70W 100W For Hazardous Areas
Download Brochure| Data | |
|---|---|
| Material | Copper-free aluminium, powder coated surface, yellow (RAL1021) Toughened glass, stands 4J impact, Stainless steel |
| Weight | 2.75~5.8kg |
| Dimensions | 210X210X373mm |
| Lamp specification | Integrated LED,Multiple LED |
| Lamp power (W) | 30W, 50W, 70W, 100W |
| Rated voltage | 220~240V AC 50/60Hz |
| 100~250V DC | |
| Rated luminous flux | 3150~10800lm |
| Terminal | 3 x 1.5~4mm2 (L+N+PE) |
| Cable entries | M25x1.5 |
| Available cable outer diameter | Φ10~Φ14 (mm) |
| Specification | |
|---|---|
| Global (IECEx) | IECEx NEP 18.0022X |
| Gas and dust | Ex db IIC T6/T5/T4 Gb; |
| Ex tb IIIC T80℃/T85℃/T95℃/T100℃ Db | |
| Europe (ATEX) | TÜV CY 19 ATEX 0206175X |
| Gas and dust | Ex II 2 G Ex db IIC T6/T5/T4 Gb |
| Ex II 2 D Ex tb IIIC T80℃T85℃/T95℃/T100℃ Db | |
| Certificates | IECEx; ATEX; CU-TR |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66 |
| Ambient temperature | T6/T80℃ for Tamb: -20℃~+43℃,T5/T95℃ for Tamb: -20℃~+58℃ |
