HRD96 Series Explosion Proof LED Light Fittings 30W 60W 120W For Dangerous Locations
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021)Toughened glass, stands 4J impact |
| Weight | 2~5.5kg |
| Dimensions | 316x316x118mm |
| Lamp specification | LED module, Multiple LED |
| Lamp power (W) | 30W, 60W, 120W |
| Rated voltage | 220~240V AC 50/60Hz |
| Rated luminous flux | 3150~12300lm |
| Terminal | 3 x 1.5~4mm2 (L+N+PE) |
| Cable entries | M25 x 1.5 |
| Available cable outer diameter | Φ10~Φ14 (mm) |
| Specification | |
|---|---|
| Global (IECEx) | IECEx (applied for) |
| Gas and dust | Ex db IIC T6 Gb |
| Ex tb IIIC T80℃ Db | |
| Europe (ATEX) | ATEX (applied for) |
| Gas and dust | Ex II 2 G Ex db IIC T6 Gb |
| Ex II 2 D Ex tb IIIC T80℃ Db | |
| Certificates | IECEx; ATEX |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66 |
| Ambient temperature | -40℃~+55℃ |
