HRND95 Series LED Light Fittings Explosion Proof Work Light 40W-300W IECEx ATEX
Download Brochure| Data | |
|---|---|
| Material | Copper- free Aluminium Alloy, powder coated surface, Toughened glass, stands 4J impact |
| Lamp specification | LED module, Multiple LED |
| Lamp power (W) | 40W, 60W, 80W, 120W, 160W, 200W, 240W, 300W |
| Rated voltage | 100~277V AC 50/60Hz,130~250V DC |
| Rated luminous flux | 6400~46000lm |
| Terminal | 3 x 1.5~4mm2 (L+N+PE) |
| Cable entries | 1×M20×1.5 cable gland(DQM-I Ex e) |
| Available cable outer diameter | M20x1.5 |
| Specification | |
|---|---|
| Global (IECEx) | IECEx EUT 18.0002X |
| Gas and dust | Ex nR IIC T□1) Gc |
| Ex tc IIIC T□1) Dc IP66 | |
| Europe (ATEX) | EPTI 18 ATEX 0346 X |
| Gas and dust | Ex II 3 G Ex nR IIC T□1) Gc |
| Ex II 3 D Ex tc IIIC T□1) Dc IP66 | |
| Certificates | IECEx; ATEX |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66 |
| Ambient temperature | -40℃~+55℃(+40℃) |
