HRNT95 Series Explosion Proof LED Light Fittings Atex Led Floodlight 5000K
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy, powder coated surface, Toughened glass, stands 4J impact |
| Lamp specification | LED module, Multiple LED |
| Lamp power(W) | 80W,120W,150W,200W,240W,300W |
| Colour temperature (CCT) | 5000K |
| Rated voltage | 100~277V AC50/60Hz,130~250V DC |
| Degree of protection | IP66 |
| Ambient temperature | -40°C~+55°C |
| Terminal | 3x1.5~4mm2 (L+N+PE) |
| Cable entries | 1x M20x 1.5 cable gland (DQM-I Ex e) |
| Specification | |
|---|---|
| Global (IECEx) | IECEx EUT 18.0003X |
| Gas and dust | Ex nR IIC T□1) Gc |
| Ex tc IIIC T□1)Dc | |
| Europe (ATEX) | EPTI 18 ATEx 0344X |
| Gas and dust | Ex II3 G Ex nR IIC T□1) Gc |
| Ex II3 D Ex tc IIIC T□1) Dc | |
| Certificates | IECEx; ATEX |
| Conformity to standards | EN 60079-0, EN 60079-15, EN 60079-31 |
| IEC60079-0. IEC 60079-15, IEC 60079-31 | |
