HRT96 Series Explosion Proof LED Floodlights 5700K 80W 160W 240W IP66
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021) Toughened glass, stands 4J impact Stainless steel |
| Lamp specification | LED module, Multiple LED |
| Lamp power (W) | 80W,160W,240W |
| Colour temperature (CCT) | 5700K |
| Rated voltage | 220~240VAC50/60Hz |
| Degree of protection | IP66 |
| Ambient temperature | -40°C~+55°C |
| Mounting | Fixed type, street lamp type |
| Cable entries | M25 x 1.5 plugs |
| Cable gland | DQM-Il(Ex d)or DQM-Ill(Ex d)is r |
| Specification | |
|---|---|
| Global(IECEx) | IECEx(applied for) |
| Gas and dust | Ex db IIC T6 Gb |
| Ex tb IIIC T80℃ Db IP66 | |
| Europe(ATEX) | ATEX (applied for) |
| Gas and dust | Ex II 2 G Ex db IIC T6 Gb |
| Ex II 2 D Ex tb lllC T80℃ Db IP66 | |
| Certificates | IECEx ; ATEX |
| Conformity to standards | EN 60079-0,EN 60079-1,EN60079-28,EN 60079-31 |
| IEC60079-01EC 60079-1,IEC60079-28IEC 60079-31 | |
