BQD Series Explosion Proof Motor Starters (Ex D IIB) 380V 400VAC 50/60Hz Flame Proof
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy, powder coated surface |
| Weight | 20.00~54.50kg |
| Dimensions | As per design |
| Enclosure colour | Window grey (RAL7040) |
| Exposed fastener | Stainless steel |
| Rated voltage | 380/400V AC 50/60Hz |
| Internal&external earthing | M6/M8 |
| Cable entries | Standard M□ x 1.5 plug |
| Cable gland (optional) | DQM-II(Ex d),DQM-III(Ex d) |
| Entry direction | Bottom |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CNEX 18.0035X |
| Gas and dust | Ex db IIB T6 or T5 Gb |
| Ex tb IIIC T80℃ or T95℃ Db | |
| Europe (ATEX) | CNEX 18 ATEX 0028 X |
| Gas and dust | Ex II 2 G Ex db IIB T6 or T5 Gb |
| Ex II 2 D Ex tb IIIC T80℃ or T95℃ Db | |
| Certificates | IECEx; ATEX |
| Conformity to standards | EN;IEC |
| Degree of protection | IP66 |
| Ambient temperature | T6/T80℃ for Tamb: -60℃~+50℃ |
| T5/T95℃ for Tamb: -60℃~+60℃ | |
