BQD Series Explosion Proof Motor Starter (Ex D E IIC) IP65 Waterproof Industrial
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy, powder coated surface |
| Color | Window grey (RAL7040) |
| Dimensions | As per design |
| Rated voltage | 380/400V AC 50/60Hz |
| Internal&external earthing | M6/M6 |
| Cable entries | Standard M□ x 1.5 plug; |
| Cable gland (optional) | DQM-I (Ex e) |
| Entry direction | Bottom |
| Surface Mounting | Standard |
| Pedestal Mounting | Optional |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 11.0017X |
| Gas | Ex d e IIC T6 Gb |
| Europe (ATEX) | LCIE 10 ATEX 3075 |
| Gas | Ex II 2 G Ex d e IIC T6 |
| Certificates | IECEx; ATEX |
| Conformity to standards | EN;IEC |
| Degree of protection | IP65 |
| Ambient temperature | -20℃~+55℃ |
