HRY92-LED Series Fluorescent Light Fittings Explosion Proof 20W 40W 60W 5000K
_509206da37eaabafd1f34234d5c87c62bf21a94ed27c9f25290f4c70f2d90c1d.DWYx7_nF.webp)
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy, powder coated surface, |
| yellow (RAL1021) | |
| Weight | 5.75~10.33kg |
| Dimensions | 1365x180x165mm |
| Lamp specification | LED module(supplied with the light fittings) |
| Lamp power (W) | 20W,40W,60W |
| LED Colour Temperature | 5000K |
| Rated voltage | 100-277V AC 50/60Hz |
| Earthing protection | M5(interal & external earth bolts) |
| Terminal | 3 x 1.5~4mm2 (L+N+PE) |
| Cable entries | 2 x M25 x 1.5 plugs |
| Cable gland | DQM-II or DQM-III is recommended |
| Specification | |
|---|---|
| Global(IECEx) | IECEx CQM 24.0040X |
| Gas and dust | Ex Ex db IIB T6 Gb |
| Ex Ex db IIB+H2 T6 Gb | |
| Ex Ex tb IIC T80℃ Db | |
| Europe (ATEX) | ATEX(applied for) |
| Gas and dust | Ex II 2 G Ex db IIC T6 Gb |
| Ex II 2 G Ex db IIB+H2 T6 Gb | |
| Ex II 2 D Ex tb IIC T80℃ Db | |
| Certificates | IECEx,ATEX |
| Conformity to standards | EN.IEC |
| Degree of protection | IP66 |
| Ambient temperature | -60℃~+55℃;-20℃~+55℃ |
