HRY97 Series Explosion Proof Led Light Fixture High Efficiency Energy Saving Atex IP66
Download Brochure| Data | |
|---|---|
| Material | Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021) |
| Weight | 5.50~6.50kg |
| Dimentions | |
| Lamp specification | LED module (supplied with the light fittings) |
| Lamp power (W) | 20W, 40W, 60W |
| LED Colour temperature (CCT) | 5000K |
| Note: nature white is available in general. Warm white or cool white is optional, | |
| please specify when ordering. | |
| Rated voltage | 100-277V AC 50/60Hz 130~250V DC |
| Earthing protection | M4 (internal & external earth bolts) |
| Terminal | 3 x 1.5~4mm2 (L+N+PE) |
| Cable entries | 12x M25 x 1.5 plugs |
| Specification | |
|---|---|
| Global (IECEx) | IECEx CQM 24.0001X |
| Gas and dust | Ex db eb mb llC T5/T4 Gb') |
| Ex tb lC T70℃/T90℃ DЫ') | |
| Europe(ATEX) | TÚV CY 25 ATEX 0207222 X |
| Gas and dust | Ex II 2 G Ex db eb mb llC T5/T4 Gb') |
| Ex II 2 D Ex tb lIC T70℃/T90'℃ Db') | |
| Certificates | IECEx; ATEX; |
| Conformity to standards | EN.IEC |
| Degree of protection | IP66 |
| Ambient temperature | -40℃~+60℃ |
